TENSE AVR-63T – Adjustable Current & Voltage Relay – 63A
- Key parts explained:
- Red displays (A L1, L2, L3): Show current/amps on each of the 3 phases
- Yellow displays (V L1, L2, L3): Show voltage on each phase
- Adjustable knobs: You can set the limits yourself
– A>: Over-current protection. Trips if current goes above what you set, max 63A
– U>: Over-voltage protection. Trips if voltage goes above set limit, like 230V
– U<: Under-voltage protection. Trips if voltage drops below set limit, like 210V
– DT: Delay Time – how long to wait before tripping
– RT: Recovery Time – how long to wait before turning back ON - Input N, L1, L2, L3: Main supply from K-Electric/WAPDA connects here
- Output N, L1, L2, L3: Your home/DB connection goes from here
- This device protects your appliances from voltage and current problems
